LICENSING | CNCNETPDM MANUAL

TOP

When you start the program or service the first time without a license CNCnetPDM automatically creates a license key for your copy. Without a purchased license key initially this is a demo license for an unlimited number of devices. This is ideal for testing. The ONLY limitation of this license type is that device drivers and diagnostic programs output a restricted number of configured items.

LICENSE TYPES | REQUEST A LICENSE | UPDATE A LICENSE | IMPORTANT NOTES

Information about your license is stored in file log_master_YYMMDD.txt in the log directory of CNCnetPDM. In addition entry License = Your license number is created in section [GENERAL] of configuration file CNCnetPDM.ini

LICENSE TYPES

There are 3 possible licensing options for CNCnetPDM:

LICENSE TYPE

DESCRIPTION

Demo License
(Default)

For an unlimited number of devices. Device drivers output a restricted number of configurable items.

Device License

Limited to a specific number of devices on a single server, unlimited output

Server License

Unlimited number of devices on a single server, unlimited output

 FIG 1:  Available license types for CNCnetPDM

For information about license fees please see: Licenses

Time-limited versions of license types Device or Server are available. To purchase a license or get a time-limited license for testing please contact our sales and support department.

REQUEST A LICENSE

You have two possible options to obtain an updated license:

  1. Copy your current license key from log-file log_master_YYMMDD.txt or from CNCnetPDM.ini and send it by email to the sales and support department.
  2. Double click on CNCnetControl.exe with your service running. Click on Button ‘View / Edit’ under ‘License’, an additional dialog opens:

FIG 2:  CNCnetPDM license dialog (CNCnetControl)

On top (1) you see details about your current license, a demo license always shows up as ‘expired’. If you click on the button (2) right of field ‘Current License Number’ your license number is copied to the clipboard. Paste it into an email and send it to our sales and support department.

UPDATE A LICENSE

To register a new license key received from inventcom you also have two options.

  1. Exchange your current license number in file CNCnetPDM.ini with the one received from inventcom and restart the program or service.
  2. Double click on CNCnetControl.exe with your service running. Click on Button ‘View / Edit’ under ‘License’. Copy the license key from the email received from inventcom to the clipboard.

    Click on the button (3) right of field ‘New License Number’, this pastes the new license key into the appropriate field. If you entered a valid license key button OK gets activated. Clicking on OK immediately registers the license. In case everything worked well the information in the top area (1) of the license dialog changes accordingly. Restart the program or service for the changes to take effect.

NOTES

Important: If you enter an invalid license key, copy your program to another PC, activate MS Windows at a later time or apply a major update that changes the Operating System of the PC CNCnetPDM automatically creates a new demo license on next startup.

  • If you have a valid license for CNCnetPDM please contact sales and support before changing PCs, activating MS Windows or applying major updates that change the Operating System of the PC!
