HEIDENHAIN PART COUNTER DATA | NEWS

TOP

As you may know Heidenhain controllers by design have no built in part counter. However, the most recent CNCnetPDM device driver for Heidenhain TNC and iTNC devices now allows you to automatically acquire part counter data without any user intervention required at the machine.

Reading of Heidenhain part counter data (TNC 640)

FIG 1:    Workpiece counter output (TNC 640)

The technique can be setup in a few steps and works reliable for older TNC 426, 430 and newer iTNC 530, TNC 320, 620 and 640 controllers.

SETUP

On Friday June 11, 2021 we released instructions on setup and reading of Heidenhain workpiece counters with CNCnetPDM:
https://www.inventcom.net/support/heidenhain/read-part-counters

DEVICE DRIVER

The newest device driver that supports part counting can be found here:
https://www.inventcom.net/support/heidenhain/tnc-device-driver

Please contact us if you have any questions!
